Vortex Diamondback HD 16-48x65 Angled Spotting Scope with Stay-On case Lifetime Warranty
Get closer to the action with the Vortex Diamondback HD 16–48x65 Angled Spotting Scope—designed to deliver impressive clarity, portability, and reliability in the field. Featuring a versatile 16–48x zoom range and a 65mm objective lens, this scope provides bright, sharp images with excellent detail, even in challenging light conditions. The HD optical system enhances resolution and color fidelity, making it ideal for birdwatching, wildlife observation, and target spotting. Its angled eyepiece ensures comfortable viewing over extended periods and easier sharing between users. Built tough with a rugged, rubber-armored body, it’s fully waterproof and fog-proof for dependable performance in any environment. Complete with a protective stay-on case and backed by Vortex’s lifetime warranty, this spotting scope is a trusted companion for every outdoor adventure.
-Nathan (Technical Advisor)
Vortex Diamondback HD 16-48x65 Angled Spotting Scope
Glassing out west demands an HD optic, but other systems can't get you the clarity you need to see a tail twitch in low light, or pick a tine out of dense cover.
The redesigned Diamondback HD spotting scopes have all the horsepower the long-distance hunter needs, and they excel in low light - right when you need it most.
We've also streamlined the exterior for a sleeker, snag-free profile, building in a helical focus wheel.
Vortex Diamondback HD 16-48x65 Angled Spotting Scope
- Magnification 16-48x
- Objective Lens Diameter 65 mm
- Linear Field of View 138-72 ft/1000 yds
- Angular Field of View 2.6-1.4 degrees
- Close Focus 16.4 feet
- Eye Relief 20.3-18.3 mm
- Exit pupil: 4.0-1.35mm
- Length 14.25 inches
- Weight 49.8 oz
Vortex Diamondback HD 16-48x65 Angled Spotting Scope
HD Optical System
Optical Features
Optimized with select glass elements to deliver an exceptional resolution, cut chromatic aberration and provide outstanding colour fidelity, edge-to-edge sharpness and light transmission.
Fully Multi-Coated
Increase light transmission with multiple anti-reflective coatings on all air-to-glass surfaces.
Construction Features
ArmorTek ®
Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
Waterproof
O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.
Shockproof
Rugged construction withstands recoil and impact.
Fogproof
Argon gas purging prevents internal fogging over a wide range of temperatures.
Rubber Armor
Provides a secure, non-slip grip, and durable external protection.
Convenience Features
Adjustable Eyecups
Twist up and down for comfortable viewing with or without eyeglasses.
Helical Focus
Allows for fast and fine adjustments.
Arca-Swiss Compatible
Directly mounts to Arca-Swiss tripod heads without the use of additional plates. Also accepts 1/4-20 threads for use on alternate style tripod heads.
Tripod Adaptable
Allowing use on a tripod or car window mount. Tripod adapter required.
Rotating Tripod Ring
Allows rotation of the eyepiece to a sideways position, providing adjustable viewing angles.
Built-in Sunshade
Reduces glare and shields the objective lens from raindrops and snow.
Vortex Diamondback HD 16-48x65 Angled Spotting Scope
Vortex Diamondback HD 16-48x65 Angled Spotting Scope
- Vortex Diamondback HD 16-48x65 Angled Spotting Scope
- Neoprene cover
- Tethered objective lens cap
- Tethered ocular lens cap
- Lens cloth
1. What is the magnification range of this spotting scope?
It offers a 16x to 48x zoom range for versatile viewing at different distances.
2. Is it suitable for low-light conditions?
Yes, the 65mm objective lens provides good light transmission for clear images during dawn and dusk.
3. What does the HD optical system provide?
It enhances image clarity, sharpness, and color accuracy for a more detailed viewing experience.
4. Why choose an angled spotting scope?
An angled design allows for more comfortable viewing over long periods and easier use on a tripod.
5. Is the scope waterproof and fog-proof?
Yes, it is fully sealed and nitrogen-purged for reliable all-weather performance.
6. What is included with the scope?
It comes with a stay-on case that protects the scope during use and transport.
7. What activities is this scope best for?
It’s ideal for birdwatching, wildlife observation, hunting, and target shooting.
8. Is it portable compared to larger scopes?
Yes, the 65mm size makes it lighter and easier to carry while still offering strong performance.
9. Can it be mounted on a tripod?
Yes, it is tripod compatible for stable, hands-free viewing.
10. Does it come with a warranty?
Yes, it is backed by Vortex’s lifetime warranty for long-term peace of mind.
Vortex Diamondback HD 16-48x65 Angled Spotting Scope
- Vortex VIP Lifetime Warranty
