HIKMICRO Condor CH25L Thermal Monocular with LRF
25mm <20mK 384x288px 12µm
- 384x288 VOx thermal sensor with <20mK NETD for outstanding clarity and detail recognition
- Bright 25mm F1.0 lens with up to 1,200m detection range and 18.3m field of view at 100m
- Integrated laser rangefinder with ±1m accuracy up to 1,000m for precise distance measurement
- Lightweight, ergonomic design with skin-friendly grip for comfortable one-handed use
- Rugged magnesium alloy housing with IP67 waterproof and dustproof protection
- Three replaceable rechargeable batteries for up to 6 hours continuous operation
See clearer, range farther, and act with confidence using the HIKMICRO Condor CH25L Thermal Monocular.
Designed for hunters, security professionals, and serious outdoor users, this compact device delivers real answers to real problems—like spotting game in fog, getting accurate range in the dark, or scanning wide fields without missing a thing.
Built around a 384×288 VOx thermal sensor with <20 mK sensitivity, the CH25L provides stunning thermal clarity even in challenging weather. Whether you're wondering what’s the best thermal monocular with a rangefinder or how to improve nighttime visibility while keeping gear light, this unit covers it all.
- Integrated LRF – Accurately range targets from 10–1,000 m with ±1 m precision
- Powerful Zoom – 2.5×–20× magnification + Zoom Pro for crisp, noise-free details
- Detection Range – Thermal vision up to 1,200 m, even in low contrast scenes
- Built-In Recording – Photo, video, and audio logging with 64 GB internal memory
- Wi‑Fi & App Control – Share live views or manage footage on the go
- Fast Boot – 3-second startup and standby modes ensure you're always ready
- Compact Durability – Magnesium body, IP67 rated, and just 386 g in weight
- Long Runtime – Up to 4.5 hours on a single 18650 battery
From eliminating guesswork in range estimation to delivering mission-ready visibility when others can't, the CH25L isn’t just built to perform—it’s built to solve.
What’s Included: Unit, battery, USB-C cable, protective case, instructions
Use Case Ready: Perfect for wildlife tracking, search/rescue, rural security
Warranty: Full HIKMICRO manufacturer support and protection
- Image Sensor VOx Uncooled Focal Plane Array, 384x288 resolution
- Frame Rate 50Hz
- Pixel Pitch 12µm
- Spectral Range 8–14µm
- NETD <20mK (@25°C, F#=1.0)
- Lens 25mm, F1.0
- Detection Range Up to 1,200m
- Focus Mode Focus ring
- Field of View 10.5° × 7.9° / 18.3m × 13.8m @100m
- Minimum Focus Distance 2.5m
- Magnification 2.5x–20.0x (8x digital zoom)
- Display 0.39" OLED, 1024x768 resolution
- Eye Relief 15mm
- Exit Pupil 4mm
- Dioptre Adjustment -5D to +3D
- Palettes Black Hot, White Hot, Red Hot, Fusion
- FFC Modes Auto, Manual, External Correction
- Protection Level IP67
- Weight 386g (without battery)
- Dimensions 180.7 × 52.7 × 85.4mm
- Operating Temperature -30°C to +55°C
- Storage Built-in 64GB EMMC
- Wireless Connectivity Wi-Fi hotspot
- Battery Type Replaceable, rechargeable Li-ion 18650
- Battery Life 6 hours (with LRF & hotspot on, three supplied batteries)
- Charging USB-C, 5V DC 2A, supports external power supply
- Laser Rangefinder Class 1, 905nm, up to 1,000m, ±1m accuracy, 10m minimum
- High-Sensitivity Imaging: <20mK NETD thermal detector easily reveals small details in varied weather and light conditions.
- Optimised Image Processing: HIKMICRO’s proprietary image algorithms enhance clarity and detail across diverse hunting and observation scenarios.
- Laser Rangefinder Precision: Measures distances up to 1,000m with ±1m accuracy for improved safety and targeting decisions.
- Ergonomic Handling: Compact, hand-fitting design with soft, skin-friendly materials ensures comfort for both left- and right-handed users.
- Rugged Reliability: Magnesium alloy construction combines lightweight portability with durability for long-term field use.
- Long-Lasting Power: Supplied with three 18650 rechargeable batteries, each offering up to 2 hours (LRF on), for a total of 6 hours use.
- Energy-Saving Auto Screen-Off: Automatically powers down when tilted or lowered to conserve battery life.
- Custom Visual Experience: Adjustable contrast, sharpness, and other visual parameters via a user-friendly hierarchical menu.
- Seamless Connectivity: Built-in Wi-Fi hotspot for use with the HIKMICRO Sight app as a second display and for media sharing.
- Media Capture: Records photos and videos with audio to 64GB internal storage for easy sharing and playback.
HIKMICRO Condor CH25L Thermal Monocular with LRF - 25mm <20mK 384x288px 12µm
Q: What is the detection range of the CH25L?
A: With its 25 mm lens and 384×288 12 µm sensor, it can detect a human-sized target out to around 1,200 m.
Q: What does the built-in LRF (laser rangefinder) do?
A: It provides fast, accurate distance readings up to 1,000 m, helping you quickly gauge range without guesswork.
Q: Can I record or stream footage?
A: Yes—the Condor has onboard photo and video recording, plus Wi-Fi streaming via the Hikmicro app so you can view, save, and share in real time.
Q: How long is the battery life?
A: Runtime is typically 6–7 hours on a full charge (Wi-Fi off). Extra batteries can be swapped in for extended use.
Q: Is the unit durable for outdoor use?
A: Yes—it’s IP67 waterproof, shockproof, and built to perform in all weather conditions.
Q: What is the advantage of the 12 µm pixel pitch sensor?
A: The finer pixel pitch gives sharper images and better detail recognition at distance compared to older 17 µm sensors.
Q: How heavy is it? Can it be carried easily?
A: It’s lightweight and compact, designed for easy handheld use and long sessions without fatigue.
About thermal detection ranges:
Thermal monoculars list their maximum detection range, which is the distance at which a human-sized object can be noticed. However, detection is not the same as recognition or identification. Clarity depends on sensor resolution, lens size, and zoom used.
- Detection: You can see something is there (e.g. a heat source).
- Recognition: You can tell what type of object it is (e.g. human vs animal).
- Identification: You can distinguish exact details (e.g. species or equipment).
About digital zoom:
Digital zoom increases magnification by cropping and enlarging the sensor image. This can help with recognition at range but reduces image sharpness. Native optical magnification always gives the clearest view, with digital zoom best used to confirm detail when needed.
Q: Why is “detection range” longer than useful range?
A: Detection only means spotting a heat source—identification usually requires a shorter distance.
Q: How far can I actually identify targets?
A: Typically half or less of the quoted detection distance, depending on sensor resolution and conditions.
Q: Does digital zoom reduce clarity?
A: Yes—because it enlarges pixels. It’s useful for a closer look but best combined with optical zoom.
Q: Should I rely on maximum zoom?
A: Use sparingly—optical zoom or getting closer will always give a sharper, more reliable image.
FAQ - Thermal Imager: Wi-Fi Streaming & Recording
Modern thermal imagers often feature built-in Wi-Fi and digital storage, allowing you to stream live video, record footage, and share images directly from the device. This is invaluable for reviewing hunts, training sessions, or search operations where evidence and communication matter.
Q: How does Wi-Fi streaming work?
A: The thermal imager creates its own hotspot. You connect your phone or tablet via the manufacturer’s app to view, control, and record.
Q: Is the video stored on the device?
A: Yes—most units include internal storage (often 8–16 GB) for photos and video.
Q: Does Wi-Fi affect battery life?
A: Yes—streaming reduces runtime. For longest sessions, turn Wi-Fi off when not needed.
Q: Can I share recordings later?
A: Absolutely—footage can be transferred to a PC or mobile device for editing, training, or evidence use.
Q: Is image quality reduced when streaming?
A: Streaming resolution may be lower than the device’s display, but saved recordings retain native quality.
FAQ - Laser Rangefinders in Thermal Devices
A laser rangefinder (LRF) uses a precise laser pulse to measure the distance to a target. Built into thermal imagers, it provides accurate range data instantly, making it much more reliable than stadiametric (digital guess-based) ranging.
Q: Why is an LRF useful in a thermal imager?
A: It removes guesswork, giving exact distance to target, which is crucial for ranging shots or navigation.
Q: How does it compare to digital rangefinding?
A: Digital stadiametric rangefinding estimates distance based on assumed target size; LRF gives an exact laser measurement.
Q: What’s the typical range of an LRF in thermal units?
A: Many models, like the Hikmicro Condor, measure reliably to around 1,000 m.
Q: Does using the LRF affect image quality?
A: No—the LRF is separate from the thermal sensor, so it won’t reduce clarity or performance.
Q: Who benefits most from LRF integration?
A: Hunters, tactical users, and search & rescue teams needing accurate distance information instantly.
