Pixfra™ Arc LRF A650 Pro Thermal Monocular w/Laser Rangefinder (640x512 12µm Detector/50mm Lens)
- High-resolution 640×512, 12µm thermal sensor with <20mK NETD for exceptional image detail.
- 50mm f1.0 lens with 15.4 × 12.3m field of view @ 100m and detection range of up to 2600m.
- Integrated laser rangefinder with 1000m range and ±1m accuracy for precise distance data.
- Durable magnesium alloy housing with IP67 weatherproof protection.
- Up to 6 hours runtime with replaceable 18650 batteries and USB-C charging.
- Pixfra Outdoor app compatibility for real-time wireless sharing with up to four users.
Finance Calculator
Representative Calculation
Powered by Autify Digital Ltd
The Pixfra™ Arc LRF A650 Pro Thermal Monocular combines outstanding long-range thermal performance with precise distance measurement, delivering unmatched clarity and accuracy in the field. Equipped with a highly sensitive 640×512, 12µm <20mK NETD thermal sensor and a fast 50mm f1.0 lens, the A650 Pro achieves a wide 15.4 × 12.3m field of view at 100m and an extended detection range of up to 2600m. Its seamlessly integrated laser rangefinder provides accurate measurements up to 1000m with ±1m precision, allowing for confident, informed decisions during observation. Built in a rugged magnesium alloy housing with IP67 protection, this device is lightweight, ergonomic, and ready for any environment. With extended battery life, intuitive controls, and wireless app connectivity, the A650 Pro is an indispensable companion for wildlife observation, hunting, and professional fieldwork.
- Detector Type Vanadium oxide uncooled focal plane detector
- Thermal Sensor 640×512, 12µm, <20mK NETD
- Frame Rate 50 Hz
- Lens 50mm f1.0
- FOV (m @ 100 m) 15.4 × 12.3
- Thermal Focus Control Manual
- Close Focus Distance 2 m (6.56 ft)
- Rangefinder Built-in precision laser rangefinder
- Distance Measurement Range 1000 m
- Digital Zoom 1x, 2x, 4x, 8x
- Magnification 3.37x
- Colour Palettes 6 (white hot, black hot, iron red, alarm, amber, emerald)
- Display 0.41″ 1440×1080 OLED
- Storage 32 GB
- Uniformity Correction Auto, manual
- Picture in Picture (PiP) Yes
- Audio Recording Yes
- Hot Spot Trace Yes
- Wi-Fi Yes
- Power Supply 5 VDC/1 A, USB Type-C
- Battery Type 1 replaceable 18650 battery
- Battery Capacity 3,200 mAh
- Battery Operating Life Up to 6 hours (depending on temperature)
- Environmental Protection IP67
- Product Dimensions 186 × 59 × 82 mm / 7.32″ × 2.32″ × 3.23″ (L × W × H)
- Packaging Dimensions 228 × 120 × 187 mm / 8.98″ × 4.72″ × 7.36″ (L × W × H)
- Weight 430 g
- Long-range Thermal Capability: The 50mm f1.0 lens and sensitive 640×512 thermal sensor offer superior clarity with a detection range of up to 2600m.
- Enhanced Image Processing: Pixfra’s PIPS 2.0 ensures sharp, noise-reduced, and contrast-rich thermal imagery in all conditions.
- Precision Laser Rangefinder: Seamlessly integrated LRF provides reliable measurements up to 1000m with ±1m accuracy.
- Ergonomic Comfort: Contoured eyecup and textured rubber grip offer secure handling during prolonged observation sessions.
- Rugged Lightweight Build: Compact magnesium alloy body is impact-resistant, lightweight, and built to withstand demanding fieldwork.
- All-weather Reliability: IP67 certification ensures resistance to rain, snow, fog, and high humidity.
- Uninterrupted Power: Powered by replaceable 18650 batteries for up to 6 hours operation, with secure twist-cap design and USB-C charging.
- Wireless Sharing & Recording: Wi-Fi connection with Pixfra Outdoor app allows live sharing with up to four viewers, plus Picture-in-Picture, audio recording, and hot spot tracking.
- Custom Viewing Experience: Six colour palettes, digital zoom up to 8×, and uniformity correction options allow users to adapt the display to varying conditions.
- Pixfra™ Arc LRF A650 Pro Thermal Monocular w/Laser Rangefinder (640x512 12µm Detector/50mm Lens)
- Pixfra 3 Year Warranty
